Description
| No. | ITEM | SPEC. |
| 1 | 切割范围Cutting range | 3000*1500mm |
| 2 | 激光波长 Laser wavelength | 1080nm |
| 3 | X-axis length轴行程 | 1500mm |
| 4 | Y-axis length轴行程 | 3000mm |
| 5 | z-axis length轴行程 | 250mm |
| 6 |
Position accuracy 机械定位精度 |
±0.5mm/min |
| 7 | Repeat Position accuracy机械重复定位精度 | ±0.3mm/min |
| 8 | Max Acc.speed最大加速度 | ≤1G |
| 9 |
Max Running speed 最大空程速度 |
≤80m/min |
| 10 | Laser Power激光器功率 | 2000W/3000W/4000W/6000W/12000W/20000W |
| 11 |
Laser Control system 控制系统 |
BOCI |
| 12 | Ph相数 | 1/3ph |
| 13 | 电源额定电压V | 220V/380V |
| 14 | 频率F | 50Hz/60Hz |
| 15 | Safety总电源防护等级 | IP54 |
