Description
| Model | Unit | GT32II-W1200 | GT32II-W1500 | GT32II-W2000 |
| Operating Voltage | V | 1PH AC220V±5% | ||
| Frequency | Hz | 50/60 | ||
| Power | W | 1200 | 1500 | 2000 |
| Fiber Length | M | 10 | ||
| Laser Output Connector | / | QBH | ||
| Central Wavelength | NM | 1080±5 | ||
| Cooling Method | / | Water Cooled | ||
| Weld Seam Requirement | MM | ≤1.6 | ||
| Working Temperature | ℃ | 0~ + 40 | ||
| Humidity | % | ≤70%@40℃；≤90%@20℃ | ||
| Working Shielding Gas | / | Argon/Nitrogen | ||
| Welding Wire Diameter | MM | 0.8,1.0,1.2,1.6,2.0 | ||
| Max-Welding Thickness | SS | 3.5 | 4.0 | 6.0 |
| CS | 3.0 | 3.5 | 6.0 | |
| AL | 2.5 | 3.0 | 4.0 | |
| Max-Cutting Thickness | SS | 2.0 | 3.0 | 5.0 |
| CS | 2.0 | 3.0 | 5.0 | |
| AL | / | / | / | |
| Rust Removal Width | MM | ≤120mm | ||
| Dimensions | MM | 870*400*695 | 870*400*695 | |
| Weight | KG | 74 | ||
| Welding Materials | Carbon steel, Aluminum, Galvanized sheet, Stainless steel, etc | |||
| Note: Welding parameters are for reference only. Actual parameters may deviate from the above values due to variations in welding wire diameter, weld seam width and other environmental and process factors. | ||||
