Description
| Model | Unit | GT22-IIF30N | GT22-IIF40N | GT22-IIF50N | GT22-IIF60N | GT22-IIF80N |
| Operating Voltage | V | 1PH AC220V±5% | ||||
| Frequency | Hz | 50/60 | ||||
| Power | W | 700 | 900 | 1200 | 1500 | 2000 |
| Fiber Length | M | 8 | 10 | |||
| Laser Output Connector | / | QBH | ||||
| Central Wavelength | NM | 1080±5 | ||||
| Cooling Method | / | Air Cooling | ||||
| Weld Seam Requirement | MM | ≤1.6 | ||||
| Working Temperature | ℃ | -20 ~ + 40 | ||||
| Humidity | % | ≤70%@40℃；≤90%@20℃ | ||||
| Working Shielding Gas | / | Argon/Nitrogen | ||||
| Welding Wire Diameter | MM | 0.8,1.0,1.2,1.6,2.0 | ||||
| Max-Welding Thickness | StainlessSteel | 2.5 | 3.5 | 4.5 | 5.5 | 7.0 |
| CarbonSteel | 2.5 | 3.5 | 4.5 | 5.5 | 7.0 | |
| Aluminum | 1.5 | 2 | 2.5 | 3.5 | 4.5 | |
| Rust Removal Width | MM | ≤100mm | ||||
| Dimensions | MM | 610*360*540 | 650*380*640 | |||
| Weight | KG | 28 | 35 | 40 | 45 | 47 |
| Applicable Welding Materials | Carbon steel, Aluminum, Galvanized sheet, Stainless steel, etc | |||||
| Note: Welding parameters are for reference only. Actual parameters may deviate from the above values due to variations in welding wire diameter, weld seam width and other environmental and process factors. | ||||||
